72 Te Aratau Taha Ma Te Katoa Huinga muka muka muka
Color:
Whakaahuatanga
Taputapu Taimana Huri
| Nga taonga | Cable diameter | Taumaha | |||||
| 2 cores | 4,0mm | 22.00kg / km | |||||
| 4 cores | 4,0mm | 22.00kg / km | |||||
| 6 cores | 4,0mm | 23.00kg / km | |||||
| 8 cores | 5.0mm | 27.00kg / km | |||||
| 10 cores | 5.5mm | 30.00kg / km | |||||
| 12 cores | 6.0mm | 35.00kg / km | |||||
| 24cores | 8.3mm | 40.00kg/km | |||||
| Storage temperature（℃） | -20 + 60 | ||||||
| Min Bending Radius(mm) | Maoro te waa | 10D | |||||
| Min Bending Radius (mm) |
Nga waahanga poto | 20D | |||||
| Min allowable Tensile Strength(N) |
Maoro te waa | 200 | |||||
| Min allowable Tensile Strength(N) |
Nga waahanga poto | 600 | |||||
| Crush Load (N/100mm) | Maoro te waa | 200 | |||||
| Crush Load (N/100mm) | short term | 1000 | |||||
Inner Sheath color
Tight Buffer color
Taputapu toenga
| Te taera muka | Unit | SM G652 |
SM G652D |
MM 50/125 |
MM 62.5 / 125 |
MM OM3-300 |
|
| huru | n | 1310/1550 | 1310/1550 | 850/1300 | 850/1300 | 850/1300 | |
| whakatinana | dB / km | ≤ | ≤ | ≤ | ≤3.0 / 1.0 | ≤3.0 / 1.0 | |
| 0.36 / 0.23 | 0.34 / 0.22 | 3.0 / 1.0 | —— | —— | |||
| Te Wehenga | 1550nm | Ps / (nm * km) | —— | ≤18 | —— | —— | Te Wehenga |
| 1625nm | Ps / (nm * km) | —— | ≤22 | —— | —— | ||
| Pūpū | 850nm | MHZ.KM | —— | —— | ≧ 400 | ≧ 160 | Pūpū |
| 1300nm | MHZ.KM | —— | —— | ≧ 800 | ≧ 500 | ||
| Zero dispersion wavelength | n | 1300-1324 | ≧ 1302, ≤1322 |
—— | —— | ≧ 1295, ≤1320 |
|
| Zero dispersion slope | n | ≤0.092 | ≤0.091 | —— | —— | —— | |
| PMD Maximum Individual Fiber | ≤0.2 | ≤0.2 | —— | —— | ≤0.11 | ||
| PMD Design Link Value | Horoi (nm2 * k m) |
≤0.12 | ≤0.08 | —— | —— | —— | |
| Fibre cutoff wavelength λc | n | ≧ 1180, ≤1330 |
≧ 1180, ≤1330 |
—— | —— | —— | |
| Cable cutoff wavelength λcc |
n | ≤1260 | ≤1260 | —— | —— | —— | |
| MFD | 1310nm | um | 9.2 +/- 0.4 | 9.2 +/- 0.4 | —— | —— | —— |
| 1550nm | um | 10.4 +/- 0.8 | 10.4 +/- 0.8 | —— | —— | —— | |
| He maha (NA) |
—— | —— | 0.200 + / -0.015 |
0.275 +/- 0. 015 |
0.200 +/- 0 .015 |
||
| Step(mean of bidirectional ) |
dB | ≤0.05 | ≤0.05 | ≤0.10 | ≤0.10 | ≤0.10 | |
| Irregularities over fiber length and point |
dB | ≤0.05 | ≤0.05 | ≤0.10 | ≤0.10 | ≤0.10 | |
